ZUMR – Il (HD) is a high definition, high-performance Multispectral Imaging payload with 24/7 Mission Capability with Enhanced Imagers. It is highly stabilized system with 2 LRUs (Line Replaceable Units). The multi-sensor Optronic Payloads can provide geo-referenced Day, Near Infrared and Infra-red imagery to battlefield commanders for reconnaissance and designation purposes. The Electro-Optical Payloads can be integrated on Fixed-Wing manned and unmanned aerial platforms as well as on helicopters.
ZUMR – II (HD) DAY/ NIGHT SURVEILLANCE & TARGETING PAYLOAD
Payloads
ZUMR – II (HD) DAY/ NIGHT SURVEILLANCE & TARGETING PAYLOAD
System Features
Technical Specifications
HD Day Imager
Resolution
1920 x 1080
Field of View
36.0° to 0.7°
HD Thermal Imager
Resolution
1280 x 720
Field of View
30.25° to 0.76°
Laser Target/Designator & Rangefinder
Range
20 km
Energy
100 mj
Code
NATO, Custom
Laser Pointer
700 mW / 200 mW
Iluminator
NVG Compatible
Coverage
Az: 360°; El:120°
Dia
17.7 in
Weight
48 kg
Power Requirement
200W (300W max)
