MORTARS LAUNCHERS

Effective Support weapon for short, medium and extended range targets, User friendly, reliable in all weather operations

System Features

  • Effective Support weapon for short, medium and extended range targets
  • User friendly, smooth bore, muzzle loading, reliable in all weather operations
  • All type of qualified 81mm ammunitions are usable for operations.
  • Dismantled in 3 loads (barrel, base plate, and bipod) for quick transport

Technical Specifications

LIGHT MORTAR 60 MM
BORE
60 MM
LENGTH OF BARREL
623 MM WITH BREECH
623 MM WITH BREECH
45 TO 80 DEGREES
RANGE
50 TO 2000 M
RATE OF FIRE
8 ROUNDS/ MINUTE
TYPE OF FIRING MECHANISM
MANUAL
ONE MAN PORTABLE COMMANDO MORTAR
CALIBRE
60.75 MM
LENGTH OF BARREL
550 MM
TOTAL LENGTH
595 MM
TOTAL WEIGHT
6.35 KG
RANGE
100-1200 M
ELEVATION
45-85 DEGREES
RATE OF FIRE
20 ROUNDS / MIN
MORTAR 81 MM (LONG BARREL)
TOTAL WEIGHT
41.5 KG
WEIGHT OF BARREL
14.5 KG
WEIGHT OF BASE
14.8 KG
WEIGHT OF MOUNT
12.2 KG
LENGTH OF BARREL
1.45 M
RANGE
5000 M
SHIPPING VOLUME
0.51 CUM
HEAVY MORTAR 120 MM
CALIBRE
120.15 MM
LENGTH OF BARREL
1746 MM
FIELD OF LAYING FOR ELEVATION DEGREES
45-85 DEGREES
WEIGHT OF BARREL
76 KG
TOTAL WEIGHT
402 KG
RATE OF FIRE
8 ROUNDS / MIN (NORMAL) | 12 ROUNDS (MAXIMUM)
